POWERFUL AND NEW RECORD-BREAKING INTEGRATED RANGE: THE BOSCH PERFORMANCE CX (SMART SYSTEM) E-DRIVE WITH NEW KIOX 300 DISPLAY AND INTEGRATED, REMOVABLE BATTERY OFFERS 750 WH

ROBUST METAL MUDGUARDS, PANNIER RACK, STAND AND SUPER BRIGHT, SMART LITEMOVE 110 LUX LIGHTING SYSTEM

COMFORTABLE COCKPIT WITH C.I.S. STEM WITH INTEGRATED CABLE ROUTING, PLUS RELIABLE SHIMANO DEORE 11-SPEED SHIFTING WITH WIDE GEAR RATIO (11–51)

ESCAPE THE DAILY GRIND

SUPER POWERFUL AND DYNAMIC E-MOTOR

The efficient Bosch Performance CX e-drive (Gen. 4) supports your ride up to 25 km/h with powerful 85 Nm. A well-balanced geometry makes the JARIFA² ride agile and dynamic. The strongest e-motor of Bosch is perfectly integrated into the bottom bracket area.
RECORD-BREAKING INTEGRATED RANGE AND A NEW DISPLAY

The new Bosch Powertube battery (smart system) with its record-breaking 750 Wh is perfectly integrated into the down tube, yet it can also be removed at any time for charging. Furthermore, the latest Kiox 300 offers a bigger, easily readable display with a new remote and better ergonomics. Additionally, there are more fitness features and better connectivity to all your devices, f.e. even charging your phone via a USB C port.
EXTRA-COMFORTABLE, INTEGRATED AND EASY TO RETROFIT

The JARIFA² combines MTB and trekking DNA. The cockpit with a C.I.S. 30-degree stem and ergonomic parts make your ride comfortable even on rides off the beaten track. The C.I.S. technology offers a clean cockpit with cable routing through stem and headset into the frame. Additionally, the JARIFA² can be retrofitted easily thanks to respective mounting points. On top, the JARIFA² 6.8 is approved for most trailers and for a system weight (rider plus gear and bike) of 150 kg.

Features

SPORTY YET COMFORTABLE

Our JARIFA² comes with a mountain bike geometry and is absolutely suitable for off-road use. Thanks to a shorter rear triangle, the JARIFA² rides agile, a 100 mm suspension fork and 29″ wheels with mountain bike tyres provide safety.

POWERFUL DRIVE

Inspires you to escape the daily routine: The FOCUS JARIFA² motivates you to go on long rides thanks to the powerful Bosch Performance CX e-drive (Gen. 4) with a battery of up to 750 Wh. The integrated battery can be removed for charging.

C.I.S. 30° STEM

The specially developed C.I.S. design ensures a clean look on the cockpit of the JARIFA² and always guarantees flawless shifting and braking. All cables (brakes, gears) run carefully through the stem. The 30° stem also ensures a pleasantly upright and ergonomic riding position.

Geometry

		M	L	XL
	Size	44	48	52
	Size (MM)	440	480	440
	Handlebar width	760	760	760
	Stem Length (MM)	60	60	60
	Crankarm length	170	170	170
	Seat post length (MM)	350	350	350
A	Seat tube length (MM)	440	480	440
B	Effective Top Tube (MM)	615	638	615
C	Head Tube Angle (°)	68	68	68
D	Effective Seat Tube Angle (°)	74	74	74
E	Chainstay length (MM)	470	470	470
F	Bottom bracket drop (MM)	65	65	65
G	Head Tube Length (MM)	130	140	140
H	Fork construction height (MM)	515	515	515
I	Pre-raked fork (MM)	51	51	51
J	Wheelbase length (MM)	1185	1209	1185
K	Stack (MM)	646	656	646
L	Reach (MM)	430	450	430
