The geometry of our eBIG.NINE follows one very simple principle: As sporty as possible, as comfortable as necessary. You ride to work in the morning but fancy a little off-road detour on the way home? No problem – that is what these bikes are made for!
The E8000 battery is perfectly integrated into the hydroformed down tube and delivers an impressive 500 Wh long detours home – the perfect aggregate for the new E7000 motor, which impresses commuters and sporty riders with its perfect balanced power delivery. However, for the more performance orientated rider we also offer a complete E8000 system.
HFS-hydroforming Prolite 66 triple butted aluminium 29er hardtail frame with integrated battery technology and a sporty yet comfortable geometry. ‘Smart Entry’ cable routing for rattle free running. E8000 and E7000 frame version come with casting motor bracket creating an integrated appearance of the motor into the frame as well as provides an extremely strong connection between frame and motor. Comes with integrated fixings for mudguards and side stand. Multiple fixing positions for water bottles and accessories.
A two-component battery cover, which offers the perfect protection for the internal battery of these models. The softer (outer) layer reduces noises, seals the downtube perfectly and absorbs hits from trail debris easily, while the harder (inner) layer ensures that the battery does not get damaged and gives it the structural shape.
The eBIG.NINE and eBIG.NINE EQ are not just ‘separated’ by the equipped fenders, rear racks and lights, but also by less obvious parts like grips, saddle, stem and tyres, that make the eBIG.NINE EQ more comfort and trekking orientated than the eBOG.NINE.
The eBIG.NINE offers the possibility to fit a water bottle or accessories like a lock or pump to the frame. The frame has (standard) bottle bosses on top of the down tube and at the seat tube, where a special adapter offers a very low mounting position, allowing maximum seat post insertion depth (guaranteed in all frame sizes).
Video
Specs
FRAME eBIG.NINE LITE II
FRAME SIZE S, M, L, XL
COLOR MATT MEDIUM BLUE/BLACK
FORK Suntour XCR34 LOR
BRAKES Shimano MT-200
ROTORS Shimano RT30 / Shimano RTEM300
HEADSET MERIDA 1901
HANDLEBAR MERIDA Expert CC
HANDLEBAR STEM MERIDA Expert CC
GRIP MERIDA Expert EC
DERAILLEUR (R) Shimano Deore Shadow+
SHIFTERS Shimano Deore
SEAT POST MERIDA EXPERT CC
SEAT CLAMP MERIDA Expert
SADDLE MERIDA Comp CC
PEDAL VP
CHAIN CNHG54
CHAINWHEEL Shimano CRE70-B
FREEWHEEL Shimano HG500
BOTTOM BRAKET included
HUBS Shimano MT400-B
RIM MERIDA Comp CC
AXLES MERIDA COMP TR
SPOKES Black stainless
TIRES Maxxis Ardent Race
LIGHT FRONT CG-119PG-BLACK(1)
LIGHT REAR CG-404RG-BLK
KICKSTAND CL-KA98, 29″
DRIVE UNIT Shimano E7000
BATTERY Shimano E8035
BATTERY LOCK Abus key
BATTERY CHARGER Shimano EC-E6002
DISPLAY Shimano SC-E7000
WEIGHT 21.64 kg
