The Bike

SEB is now selling the new 2021 range of Merida Ebikes. Featuring Shimano mid drive motors, these Ebikes rock and roll.

Being active is an important part of our day-to-day life. However, sometimes the ride to work or to the shops is that little bit too long or too hilly. Our eSPRESSO perfectly combines day-to-day usability with staying fit and healthy. We offer an array of frame and specification tyres: the eSPRESSO with the classic ‘diamond’ frame, the eSPRESSO L (low) with a heavily sloping top tube and the eSPRESSO CITY models with a low step through frame. All bikes are fully equipped or are ready for a rear rack, mud guards or a kick stand to be fitted.

FAST-ROLLING 700C WHEELS

All models ride on fast-rolling 700c wheels, ideal for rides on roads, lanes and smooth tracks. We fit tyres with reflective sidewalls and puncture protection that will get you to your destination quickly and safely. However, our ‘classic’ eSPRESSO frames can also take 650B wheels if needed.

MULTIPLE OPTIONS

In our eSPRESSO range, you can choose between two frame options. The frame design with integrated battery technology, or the proven semi-integrated battery frame option, so that you can find the ideal bike for your preferences and your budget. Our integrated battery models come equipped with either the super-powerful EP8 or the more economical E6100 motor, while the semi-integrated battery models feature the entry-level E5000 power unit, giving you even more choice to select the perfect eSPRESSO for your needs.

READY TO HIT THE ROAD

All our eSPRESSO models come equipped with mudguards, lights, lock, rear rack and a kickstand, making them ready for anything from the moment you leave the store.

ENERGY GUARD

A two-component battery cover, which offers the perfect protection for the internal battery of these models. The softer (outer) layer reduces noises, seals the downtube perfectly and absorbs hits from trail debris easily, while the harder (inner) layer ensures that the battery does not get damaged and gives it the structural shape.

INTERNAL CABLE ROUTING

We feature internal cable routing on all models. Cables are routed through the frame, entering and exiting through smooth sockets. Only a clever system for our internal guiding and fixing guarantees reliable and rattle free routing, whilst the cables are protected from moisture and dirt and gives the bike a cleaner look.

Video

Specifications

01. FRAME	eSPRESSO LITE II; MAT aluminium
02. SIZES	XS(43)-S(47)-M(51)-L(55)-XL(59);
03. FORK	Suntour NEX E25; Coil; 63 STR
04. DRIVE UNIT	Shimano E6100; 60Nm
05. BATTERY	Shimano E8035; 504Wh
06. BATTERY CHARGER	Shimano EC-E6002; 2A
07. DISPLAY	Shimano SC-E5000
08. REAR DERAILLEUR	Shimano Deore M592
09. SHIFTERS	Shimano Altus M3100
10. BRAKES	Shimano MT-200; 2 piston
11. ROTOR – FRONT	Shimano RT10; 180 mm
12. ROTOR – REAR	Shimano RT10; 180 mm
13. CHAINWHEEL	Shimano CRE61; 38 ATC
14. CRANK SIZE	Shimano FC-E6100; 170 mm
15. CHAIN	KMC e9S
16. CASSETTE	Shimano HG200; 11-36 ATC; 9 Speed
17. PEDAL	VP; VPE-891
18. HANDLEBAR	MERIDA EXPERT TK; MAT aluminium; 660 WHB; 15 RHB
19. HANDLEBAR STEM	MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable
20. STEM SIZE	90 mm-XS/S/M, 110 mm-L/XL
21. SEAT POST	MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB
22. SADDLE	MERIDA EXPERT TK; V-mount
23. HUB – FRONT	Shimano TX505; 100×9 WHF; 32 SPH; Centerlock
24. HUB – REAR	Shimano MT400; 142×12 WHR; 36 SPH; Centerlock
25. AXLE – REAR	MERIDA COMP TR; including removeable lever, 6/4mm allen key
26. RIMS	MERIDA COMP TK; 20 IWR; MAT aluminium
27. TYRES	Continental RIDE Cruiser; 622-50; wire; reflecting line
28. CARRIER	MERIDA MIK Carrier with Spring clip & Spanninga rear light
29. FENDER	Sunnywheel SW-FA311-60E1 (MSB)
30. KICKSTAND	CL-KA98
31. LIGHT – FRONT	Herrmans H-BLACK MR4 E
32. LIGHT – REAR	Spanninga Commuter GLOW XE















15. CHAIN	KMC Z1eHX
16. CASSETTE	Shimano Nexus CS-C7000; 5 speed
17. HUB-FRONT	Shimano MT400; 100×15 WHF; 32 SPH; Centerlock
18. HUB-REAR	Shimano Nexus Inter-5E; 135×9 WHR; 36 SPH; Centerlock
19. SPOKES	Black stainless
20. RIMS	MERIDA Comp TK; 20 IWR
21. TYRES	Continental Contact Cruiser; 700x50C; wire; reflecting line
22. HANDLEBAR	MERIDA Expert TK; 660 WHB; 15 RHB
23. HANDLEBAR STEM	MERIDA Expert CT; 31.8 DSH; adjustable
24. SEAT POST	MERIDA Expert CC; 34.9 DSP; 0 SSB
25. SADDLE	MERIDA Expert TK
26. PEDAL	VP; VPE-891
27. FENDER	Sunnywheel SW-FA311-60E1 (MSB)
28. CARRIER	MERIDA MIK Carrier with Spring clip & H-Cargo Light
29. KICKSTAND	CL-KA98
30. LIGHT-FRONT	Herrmans H-BLACK MR4 E
31. LIGHT-REAR	Herrmans H-Cargo integrated in MERIDA MIK carrier
32. FRAME LOCK	Abus 5650 LH-3 lock
